Description
The AeroCone Rain Collector is a tipping bucket rain gauge designed to meet the guidelines of the World Meteorological Organization. With the Davis rain gauge, rain enters the collector cone, passes through a debris-filtering screen, and collects in one chamber of the tipping bucket. The bucket tips when it has collected an amount of water equal to the increment in which the collector measures (0.254 mm). As the bucket tips, it causes a switch closure and brings the second tipping bucket chamber into position. The rain water drains out through the screened drains in the base of the Davis AeroCone rain collector.
The body and base of the Davis AeroCone rain collector are constructed with tough, UV resistant plastic. The tipping bucket pivots on bearings that minimize friction and wear. Stainless steel adjustment screws under each chamber of the tipping bucket allow you to fine-tune the calibration. Mounting holes are predrilled in the base and a built-in leveling trough aids in installation. A bird spike kit is included.
SPECIFICATIONS
Sensor type : tipping bucket with magnetic reed switch (contact closure)
Accuracy : ± 4%
Attached cable length: 6 m
Housing material: UV-stabilized ABS plastic
Dimensions of rain collector : 16.5 x 24 cm
Collection area : 200 cm²
Weight : 1 kg
Mounted on a stainless steel plate + handle for easier opening.
Equiped with a connector to Monitor
